Atlas Tubes India Co makes Fittings as per international standards. They are provided with some excellent features like robust construction, attractive design, smooth surface finish, etc. The manufacturing operations are performed at a highly advanced production plant that has the latest machines and equipment that are being operated by trained and skilled operators. Our workforce has vast experience, and they are expert in manufacturing Carbon Steel Buttweld Fittings with accuracy.
Carbon Steel Buttweld Fittings from Atlas Tubes India has marked its place in the market and proved their worth by serving in harsh conditions for longer periods. The credit for this goes to efforts taken by our quality control team who put all their skills and knowledge to ensure the high quality of our Carbon Steel Buttweld Fittings. Atlas Tubes India manufactures these Fittings using premium grade raw material that is purchased from government recognized and reputed vendors. Atlas Tubes India carefully checks every Carbon Steel Buttweld Fitting under several quality tests during the process. Only those Fittings are sent to the customers that pass these tests with the desired output. We promise to deliver these Fittings as per commitment within the scheduled time.
| Pipe Fittings Specifications | ASTM A234/ ASME SA234 |
|---|---|
| Carbon Steel Pipe Fittings size | Seamless Butt Weld Fittings : 1/2" - 10" Welded Butt Weld Fittings : 1/2" - 48" |
| CS Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1800, BS10 |
| Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Buttweld Pipe FittingsType | DN15-DN1200 |
| ASTM A234 Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM A234 Pipe Fitting |
| Size Range | ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM A234 Buttweld Fitting |
| ASTM A234 Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| Carbon Steel Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA 234 Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | CS 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| ASME B16.9 ASTM A234 Pipe Fittings | Factory-Made Wrought Buttwelding Fittings | Long Radius Elbows, Long Radius Reducing Elbows, Long Radius Returns, Short Radius Elbows, Short Radius 180-deg Rerurns, 3D elbows, Straight Tees, Straight Crosses, Reducing Outlet Tees, Reducing Outlet Crosses, Lap Joint Stub Ends, Caps, Reducers |
| ASME B16.28 | Short Radius Elbows, Short Radius 180-deg Returns | |
| MSS SP43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Long Radius Elbows, Straight and Reducing-on-the-Outlet Tees, Lap Joint Stub ends, caps, long radius 180 Degree returns, concentric reducers, eccentric reducers |
| Mss SP75 | Long Radius Elbows, 3R elbows, straight tees, reducing outlet tees, caps, reducers |
Seamless/ Welded 100% Radiography Tested
| Products | Size | |
| ASTM A234 Carbon Steel Elbow – Long Radius | ASTM A234 Carbon Steel Stub Ends | Sizes 1/2″ – 48″ |
| ASTM A234 Carbon Steel Elbow – Short Radius | ASTM A234 Carbon Steel Cross | |
| ASTM A234 CS 3D Elbow | ASTM A234 Carbon Steel 5D Elbow | |
| ASTM A234 Carbon Steel Reducing Elbow | ASTM A234 Carbon Steel Reducing Cross | |
| ASTM A234 CS 45° Elbow | ASTM A234 CS Tees | |
| ASTM A234 Carbon Steel Fabricated Tee | ASTM A234 CS End Cap | |
| ASTM A234 CS Reducer | ASTM A234 CS Coupling | |
| ASTM A234 Carbon Steel Concentric Reducer | ASTM A234 Carbon Steel Eccentric Reducer | |
| ASTM A234 Carbon Steel Pipe Nipple | ASTM A234 Carbon Steel Welded Pipe Fittings | |
